SMART MATRIX Error Messages

During the normal operation, the SMART MATRIX display will show CONTROL XXXX (where XXXX is the
number of active sensors).
In case of errors or detection failures, the CONTROL XXXX indication will be replaced by a message which
summarizes the type of error or failure occurred.
The error and failure messages can be classified as follows:
Errors detected by the SMART MATRIX power-on self-diagnostics
MESSAGE DESCRIPTION
EEPROM
EEPROM Memory error
ERROR
RAM CRC
RAM Memory error
ERROR
TWI BUS
Error on internal communication bus
ERROR
Errors detected on SM-DIN Boards
MESSAGE DESCRIPTION
ERR RAM RAM memory error on SM-DIN
SMDIN XX module with XX ID code
Eeprom memory error on SM-DIN
ERR EEP
module XX ID code.
SMDIN XX
ERR PRG
LEVEL XX
Sensor programming error
DEVICE
YY
ERR HW
Hardware Error on SM-DIN XX
SMDIN XX
ERR COM
Communication error with SM-DIN XX
SMDIN XX
SM-DIN XX input error
ERR I/O (The input status should be the same
SMDIN XX for all SM-DIN modules, as the inputs
are physically connected in parallel.)
ERR SPD The PRX signal is too fast and it
SMDIN XX cannot be correctly processed.
POSSIBILE SOLUTION
Press RESET to clear the alarm. All the
EEPROM configuration parameters will be reset
to default values.
Press RESET to clear the alarm. All the RAM
configuration parameters will be reset to default
values
Replace the SMART MATRIX QUILT terminal
POSSIBILE SOLUTION
Press Reset to clear the error.
Press Reset to clear the error. Then re-program
ID code and Baudrate on SM-DIN module.
Press Reset to clear the error. If the error
occurred after a style loading, then re-load the
style.
Replace the SM-DIN XX Board
Confirm ID code and Baudrate on SM-DIN
module, or check connection cables.
Confirm the connection of external input signals.
Increase the Prescaler value for PRX signal.
