How to Use this Manual
The manual is subdivided into 3 sections:
Section 1 – includes the connection diagrams and the electrical interface of the various connectors.
Section 2 – provides the operating instructions for a correct use of the SMART MATRIX QUILT terminal
as well as the parameter configuration/programming instructions and data/errors display
facilities.
Section 3 – describes the main characteristics and performances of the various system components
(TS5/TS7 sensors, SM-DIN QUILT boards.). Furthermore, it provides some details to better
understand the operating principles upon which the SMART MATRIX QUILT system is
based (SLOW-FAST Control Parameters,menagement of PRXsignal, etc.).
Symbols Used
!
This symbol is used to point-out notes, warnings and other important information.
TS5/TS7 Within this manual, the TS5/Dttt... or TS7/Dttt... sensors used for SMART MATRIX QUILT
application will be indicated with the generic wording TS5/TS7 or TS/xx
SETUP → TS/xx IDENT.
In the program function descriptions, this symbol indicates the function
(e.g. TS/xx IDENT.) within the menu item (e.g. SETUP).
SMART MATRIX QUILT
Introduction
