Single Sensor Numbering

To number a single sensor (for instance in case of sensor replacement) operate as follows:
Sensor Configuration and Numbering
Carry out all the operations described for sensor
configuration and numbering until the start numbering
screen appears.
Select the position of sensor to be re-numbered.
(LEVEL:
NN,
DEVICE:
Shim the touch light of the relevant sensor; the sensor's
led changes from flashing green to red.
To quit the identification procedure after the sensor re-
numbering.
EXIT
to return to configuration menu.
SMART MATRIX QUILT
NN)
2 - 10
