SMART MATRIX Error Messages

During the normal operation, the SMART MATRIX display will show CONTROL OK!.
In case of errors or detection failures, the CONTROL OK! indication will be replaced by a message which
summarizes the type of error or failure occurred.
The error and failure messages can be classified as follows:
Errors detected by the SMART MATRIX power-on self-diagnostics
MESSAGE DESCRIPTION
EEPROM
EEPROM Memory error
ERROR
RAM CRC
RAM Memory error
ERROR
TWI BUS
Error on internal communication bus
ERROR
Errors detected on SM-DIN Boards
MESSAGE DESCRIPTION
ERR RAM
RAM Memory error on Board SM-DIN/MTC xx
SMDIN xx
ERR EEP
EEPROM Memory error on Board SM-DIN/MTC xx
SMDIN xx
PRG_ER
SIDE x
MTC sensor programming error
SECT. xx
DEV xx
ERR COM
Communication error SMART MATRIX - SM-DIN/MTC xx
SMDIN xx
UPG MTC
MTC sensor upgrade required on Board SM-DIN/MTC xx
SMDIN xx
Failures detected by sensors during normal operation
MESSAGE DESCRIPTION
ERR_EEP
Eeprom error on DAC device number xx
DAC xx
