(*) The totale number of configured devices
number of devices previously set on
MISMATCH" error message will appear.
SAVE to save the settings.
•
Point and select
•
Set the number of levels (needle bars) within the
machine (i.e., set 02).
•
Point and select
for each level, i.e., set 02)(*).
To confirm the set values.
SAVE to save the settings and startup the numbering
procedure.
•
The example shown indicates that the numbering
(identification) procedure of the 4 configured sensors is
going to begin.
•
The display of SM-DIN Boards will show
•
The green led will flash on all sensors
•
Shim the touch light of the sensor corresponding to
LEVEL: 01,
•
The sensor's led changes from flashing green to red.
•
On SMART MATRIX display, the
fields will automatically increase to select one-by-one the
sensors to be numbered.
•
Shim the touch light of the relevant sensor and continue
with the numbering of all sensors.
At the end of the numbering operation, the configuration
menu will re-appear.
To return to
(MACHINE LEVEL
BOARDS CONFIGURATION
SMART MATRIX QUILT
Sensor Configuration and Numbering
MACHINE LEVELS.
DEV. PER LEVEL
DEVICE: 01.
SETUP menu
X DEV.PER LEVEL) must match the total
screen. Otherwise a
(number of sensors
DEVICE and LEVEL
"DEVICE NUMBER
2 - 9
