Position the mounting block behind the rack stile in the second U of the three U
1.
span. See
rack stile while positioning the mounting block.
Figure 2-6
Illustration Legend:
1 - First U
2 - Second U
3 - Third U
Hold the block in position. Push the front rail against the rack stile.
2.
Insert the 8–32 screw through the hole in the front rail and thread the screw by
3.
hand a few turns into the mounting block.
Tighten the 8–32 screw with a Phillips screwdriver while making sure that the rail is
4.
plumb with the inside edge of the rack stile.
Repeat to install other front rail on the other side of the rack
5.

Verify the Installation of the Base Module Front Rail

The rails must be parallel and properly installed before mounting the Base Module.
Verify that the rack rails are parallel with each other. See
1.
parallel, reinstall the rails. Do not proceed unless the rails are parallel.
If your rack has threaded holes, proceed to
2.
Figure 2-6. You might need to flex the front of the rail away from the
Mounting Block for Front Rail (Right Rail Shown)
Note:
The front rail should not tilt in or out.
Install the Base Module
Figure 2-7. If they are not
Mount the Base Module.
