Weights and Dimensions

Size and weight for SL150 library components both packaged for shipping and
unpackaged.
In the tables below:
• Base complete weight includes base chassis, two magazines, robot, one drive,
and one power supply.
• Expansion complete weight includes expansion chassis, two magazines, one
drive, and one power supply.
Table 1-1

Shipping (Packaged) Weights and Dimensions

Component Width
Base 63.5 cm (25 in)
Expansion 61 cm (24 in)
Tape Drive 41.6 cm (16.4 in)

Power Supply

20.3 cm (8 in)
Robot CRU 47.6 cm (18.75 in)
Op Panel CRU 24.5 cm (9.6 in)
Magazine CRU 31.1 cm (12.25 in)
Note:
You can install the SL150 in a rack with front to rear rail spacing from 457
mm (18 inches) to 902 mm (35.5 inches).
Table 1-2

Component (Unpackaged) Weights and Dimensions

Component Width
Base 48 cm( 18.9 in) std.
19 in rack
Height Depth
40.6 cm (16 in) 115.6 cm (45.5 in)
24.8 cm (9.75 in) 113 cm (44.5 in)
21 cm (8.25 in) 43.8 cm (17.25 in)
14.6 cm (5.75 in) 30.5 cm (12 in)
20.3 cm (8 in) 96.5 cm (38 in)
9.5 cm (3.75 in) 46 cm (18.1 in)
26.4 cm (10.4 in) 73 cm (28.75 in)
Height Depth
3U (13.34 cm/5.25 in) 92.5 cm (36.4 in)
Chapter 1
Library Specifications
Weight
43 kg (94.8 lbs) for
pallet and complete
weight
28.6 kg (63 lbs) for
pallet and chassis
only
15.9 kg (35 lbs) for
complete weight
12.3 kg (27 lbs) for
chassis only
3.6 kg (8 lbs)
1.6 kg (3.6 lbs)
8.3 kg (18.4 lbs)
1 kg (2.25 lbs)
3.4 kg (7.5 lbs)
Weight
24.4 kg (53.9 lbs) for
complete weight
13.1 kg (28.9 lbs) for
chassis only
1-7
