Install The Base Module Crus And Expansion Modules; Reinstall Magazines And Dress The Cables - Oracle SL150 Library Manual

Grasp the Base Module chassis by the sides and remove it from the shipping
1.
carton.
If there are no Expansion Modules for this library, install the floor in the Base
2.
Module.
See
Mount the Base
3.

Install the Base Module CRUs and Expansion Modules

Reinstall the function components removed from the defective Base Module and install
any Expansion Module.
Reinstall the Base Module components.
1.
•
•
•
•
•
•
Reinstall the Expansion Modules. See
2.
sure to install the floor in the bottom module.
Re-cable the Expansion Modules. Connect the specific Base Module port to the
3.
controller card port of the associated Expansion Module. See
Modules

Reinstall Magazines and Dress the Cables

Reinstall the cartridge magazines into all modules and dress any cabling.
Install cartridge magazines in all modules.
1.
See
Align and dress the cables. Secure the cables in the hook and loop straps, if
2.
applicable.
Figure 10-8
Install the Floor in the Bottom Expansion
Module.
Replace the Robot Module
Replace the Drive Tray
Install the Drive Slot Cover
Replace the Power Supply
Install a Power Supply Slot Cover
Replace the Front Control Panel
for details.
Replace the Cartridge Magazines.
Cable Attachment
Base Module Chassis Removal and Replacement (FRU)
Module.
Replace the Expansion FRU
Chapter 10
Chassis. Make
Cable the Expansion
