10.6.1

Boot Settings Configuration

Feature
Setup Prompt Timeout
Bootup NumLock State
Quiet Boot
Enter Setup If No Boot
Device
Enable Popup Boot
Menu
Boot Priority Selection
Power Loss Control
AT Shutdown Mode
Battery Support
System Off Mode
Fast Boot
Note
The term 'AC power loss' stands for the state when the module looses the standby voltage on the 5V_SB pins. The standby voltage is
continuously monitored after the system is turned off. If the standby voltage is not detected within 30 seconds, this is considered an AC power
loss condition. If the standby voltage remains stable for 30 seconds, it is assumed that the system was switched off properly.
Inexpensive ATX power supplies often have problems with short AC power sags. The system turns off but might not switch back on, even
when the PS_ON# signal is asserted correctly by the module. In this case, the internal circuitry of the ATX power supply has become confused.
Usually, a AC power off/on cycle is necessary to recover from this situation.
Copyright © 2014 congatec AG
Options Description
0 - 65535 Set number of seconds to wait for setup activation key. Default: 1
Note: 0 is not recommended. 65535 means infinite wait.
On Select the keyboard numlock state.
Off
Disabled 'Disabled' - Displays normal POST diagnostic messages.
Enabled 'Enabled' - Displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
No Select whether the setup menu should be started if no boot device is connected.
Yes
No Select whether the popup boot menu can be started.
Yes
Device Based Select between device and type based boot priority lists:
Type Based
'Device Based' - Select boot priority from a list of currently detected devices.
'Type Based' - Select boot priority from a list of device types even if they are not connected yet.
Remain Off Select the mode of operation if an AC power loss occurs:
Turn On 'Remain Off' - Keeps the power off until the power button is pressed.
Last State 'Turn On' - Restores power to the computer.
'Last State' - Restores the previous power state before power loss occurred.
Note: If you want to use this feature, chose an ATX type power supply.
System Reboot Select the behavior of an AT-powered system after a shutdown.
Hot S5
Auto (Battery Manager)
Select the battery system support bus.
Battery-Only On I2C Bus
Battery-Only On I2C Bus
G3/Mech Off Select the system state after a shutdown if a battery system is connected.
S5/Soft Off
Disabled
Enable to boot with a minimum set of devices.
Enabled Note: This feature has no effect on BBS / legacy boot options.
