Signal Pin # Description
TYPE10# A97 Dual use pin. Indicates to the carrier board that a Type 10 module is installed. Indicates to the carrier that a Rev.
1.0/2.0 module is installed.
TYPE10#
NC
PD
12V
This pin is reclaimed from VCC_12V pool. In R1.0 modules this pin will connect to other VCC_12V pins. In R2.0 this
pin is defined as a no-connect for Types 1-6. A carrier can detect a R1.0 module by the presence of 12V on this pin.
R2.0 module Types 1-6 will no-connect this pin. Type 10 modules shall pull this pin to ground through a 4.7k resistor.
Table 34 Power and GND Signal Descriptions
Signal Pin #
VCC_12V A104-A109
B104-B109
C104-C109
D104-D109
VCC_5V_SBY B84-B87
VCC_RTC A47
GND A1, A11, A21, A31, A41, A51,
A57, A60, A66, A70, A80, A90,
A100, A110, B1, B11, B21, B31,
B41, B51, B60, B70, B80, B90,
B100, B110
C1, C2, C5, C8, C11, C14, C21,
C31, C41, C51, C60, C70,C73,
C76, C80, C84, C87, C90, C93,
C96, C100, C103, C110, D1, D2,
D5, D8, D11, D14, D21, D31,
D41, D51, D60, D67, D70, D73,
D76, D80, D84, D87, D90, D93,
D96, D100, D103, D110
Copyright © 2014 congatec AG
Pinout R2.0
Pinout Type 10 pull down to ground with 4.7k resistor
Pinout R1.0
Description
Primary power input: +12V nominal. All available VCC_12V pins on the
connector(s) shall be used.
Standby power input: +5.0V nominal. If VCC5_SBY is used, all available
VCC_5V_SBY pins on the connector(s) shall be used. Only used for standby and
suspend functions. May be left unconnected if these functions are not used in
the system design.
Real-time clock circuit-power input. Nominally +3.0V.
Ground - DC power and signal and AC signal return path.
All available GND connector pins shall be used and tied to Carrier Board GND
plane.
TA30m16
I/O Comment
PDS Not connected to
indicate "Pinout R2.0"
I/O PU/PD Comment
P
P
P
P
