Congatec COM Express conga-TCA3 User Manual page 42

Pin Row C
C33 DDI2_CTRLDATA_AUX-
C34 DDI2_DDC_AUX_SEL
C35 RSVD
C36 DDI3_CTRLCLK_AUX+ (*)
C37 DDI3_CTRLDATA_AUX- (*)
C38 DDI3_DDC_AUX_SEL (*)
C39 DDI3_PAIR0+ (*)
C40 DDI3_PAIR0- (*)
C41 GND (FIXED)
C42 DDI3_PAIR1+ (*)
C43 DDI3_PAIR1- (*)
C44 DDI3_HPD (*)
C45 RSVD
C46 DDI3_PAIR2+ (*)
C47 DDI3_PAIR2- (*)
C48 RSVD
C49 DDI3_PAIR3+ (*)
C50 DDI3_PAIR3- (*)
C51 GND (FIXED)
C52 PEG_RX0+ (*)
C53 PEG_RX0- (*)
C54 TYPE0#
C55 PEG_RX1+ (*)
Note
The signals marked with an asterisk symbol (*) are not supported on the conga-TCA3.
Copyright © 2014 congatec AG
Pin Row D Pin
D33 DDI1_PAIR2- C88
D34 DDI1_DDC_AUX_SEL C89
D35 RSVD C90
D36 DDI1_PAIR3+ C91
D37 DDI1_PAIR3- C92
D38 RSVD C93
D39 DDI2_PAIR0+ C94
D40 DDI2_PAIR0- C95
D41 GND (FIXED) C96
D42 DDI2_PAIR1+ C97
D43 DDI2_PAIR1- C98
D44 DDI2_HPD C99
D45 RSVD C100
D46 DDI2_PAIR2+ C101
D47 DDI2_PAIR2- C102
D48 RSVD C103
D49 DDI2_PAIR3+ C104
D50 DDI2_PAIR3- C105
D51 GND (FIXED) C106
D52 PEG_TX0+ (*) C107
D53 PEG_TX0- (*) C108
D54 PEG_LANE_RV# C109
D55 PEG_TX1+ (*) C110
Row C Pin Row D
PEG_RX11+ (*) D88 PEG_TX11+ (*)
PEG_RX11- (*) D89 PEG_TX11- (*)
GND (FIXED) D90 GND (FIXED)
PEG_RX12+ (*) D91 PEG_TX12+ (*)
PEG_RX12- (*) D92 PEG_TX12- (*)
GND D93 GND
PEG_RX13+ (*) D94 PEG_TX13+ (*)
PEG_RX13- (*) D95 PEG_TX13- (*)
GND D96 GND
RVSD D97 RSVD
PEG_RX14+ (*) D98 PEG_TX14+ (*)
PEG_RX14- (*) D99 PEG_TX14- (*)
GND (FIXED) D100 GND (FIXED)
PEG_RX15+ (*) D101 PEG_TX15+ (*)
PEG_RX15- (*) D102 PEG_TX15- (*)
GND D103 GND
VCC_12V D104 VCC_12V
VCC_12V D105 VCC_12V
VCC_12V D106 VCC_12V
VCC_12V D107 VCC_12V
VCC_12V D108 VCC_12V
VCC_12V D109 VCC_12V
GND (FIXED) D110 GND (FIXED)
TA30m16 42/95
