Revision History
Revision Date (yyyy-mm-dd) Author Changes
0.1 2014-01-09
0.2 2014-07-04
1.0 2014-09-23
1.1 2015-04-15
1.2 2017-02-21
1.3 2018-12-07
Copyright © 2014 congatec AG
•
AEM Preliminary release
AEM • Deleted the variant equipped with Intel Celeron N2920 (PN: 047306) from sections 1, 2.1 and 2.5
•
Added industrial variant with PN: 047312 to conga-TCA3 Options Information in section 1 "Introduction"
• Updated the notes in section 2.1 "Feature List" and section 6.1.2 "Low Voltage Memory". Added note in section 2.2
"Supported OS"
•
Updated caution notes in sections 2.7 "Environmental Specifications" and 4 "Heatspreader". Updated section 7.3
"USB Port Mapping"
• Deleted support for MIPI interfaces from the whole document
•
AEM Added UART interface to the block diagram and to section 2.1 "Feature List"
• Updated section 5.1.13 "General Purpose Serial Interface"
• Deleted the conga-TCA3 PWR_OK input circuitry in section 5.1.14 "Power Control" because the circuitry is not
implemented in conga-TCA3
• Added note about the configuration of fan_pwm pin as push-pull in section 6.1.3.3 "Fan Control" and table 14
"Miscellaneous Signal Description"
•
Updated section 7.1.1.1 "Intel Virtualization Technology"
• Deleted the active cooling sub-section from section 7.1.1.3 "Thermal Management" because the BIOS does not
support this feature
• Added sections 9 "System Resources", 10 "BIOS Setup Description" and 11 "Additional BIOS Features"
•
Official release
AEM • Updated the note in section 2.2 "Supported Operating Systems"
•
Added note about Intel's HSIC errata (USB ports 4-7 reset) to sections 5.1.4 "USB 2.0" and 7.3 "USB Port Mapping"
AEM • Updated the notes in sections 2.1 "Feature List", 2.2 "Supported Operating Systems" and 6.1.2 "Low Voltage Memory
(DDR3L)"
• Updated section 2.7 "Environment Specifications" and added CSP dimensions to section 4
• Added note about UART limitations in section 5.1.13 " General Purpose Serial Interface (UART)"
•
Deleted the statement that the fan_pwm signal was configured as push-pull in section 6.1.3.3 "Fan Control" and table
14 "Miscellaneous Signal Description"
• Deleted section 6.1.3.7 "Power Loss Control" because of duplication
• Corrected the statement that PWRBTN# signal is active on rising edge in table 16 "Power and System Management
Signal Descriptions"
• Corrected the description of pins D63 and D64 in table 28 "Connector C-D Pinout"
• Updated section 10 "BIOS Setup Description"
AEM • Updated the information about handling electrostatic sensitive devices in preface section
• Updated the note in section 2.2 "Supported Operating Systems"
•
Changed the reference in the note in tables 30, 31 and 32 to section 8.4
• Updated section 10 "BIOS Setup Description"
TA30m16 2/95
