10.4.6

Module Serial Ports Submenu

Feature
Serial Port 0
Serial Port 1
10.4.7

Reserve Legacy Interrupt Submenu

Feature
Reserve Legacy Interrupt
1/2/3
10.4.8

ACPI Submenu

Feature
Enable ACPI Auto
Configuration
Enable Hibernation
ACPI Sleep State
Lock Legacy Resources
LID Support
Sleep Button Support
Copyright © 2014 congatec AG
Options Description
Disabled Enable or disable the module's serial port 0.
Enabled
Disabled Enable or disable the module's serial port 1.
Enabled
Options Description
None Use this feature to reserve the interrupt for a legacy bus device.
IRQ3 Note: The selected interrupt will not be assigned to a PCI/PCIe device.
IRQ4
IRQ5
IRQ6
IRQ10
IRQ11
IRQ14
IRQ15
Options Description
Disabled
Enable or disable BIOS ACPI auto configuration.
Enabled
Disabled Enable or disable the system's ability to hibernate (OS S4 sleep state).
Enabled
Note: If you want to use this feature, ensure that the operating system supports it.
Suspend Disabled Select the state for ACPI system sleep/suspend.
S3 (Suspend to RAM)
Disabled Enable this feature to lock legacy resources.
Enabled
Disabled If this feature is enabled, COM Express LID# signal acts as ACPI lid.
Enabled
Disabled If this feature is enabled, COM Express SLEEP# signal acts as ACPI sleep button.
Enabled
