10.4.25

Network Stack

Feature
Network Stack
Ipv4 PXE Support
Ipv6 PXE Support
PXE boot wait time
10.4.26

CSM Submenu

Feature
Launch CSM
CSM16 Module Version
Gate A20 Active
Option ROM Messages
INT19 Trap Response
Boot Option Filter
Network
Storage
Video
Other PCI Devices
Copyright © 2014 congatec AG
Options Description
Enabled Enable or disable the UEFI network stack.
Disabled
Enabled If disabled, IPV6 PXE boot option will not be created.
Disabled
Enabled If disabled, IPV6 PXE boot option will not be created.
Disabled
0 - 5 Select wait time to press ESC and abort the PXE boot.
Options Description
Enabled Enable or disable the compatibility support module.
Disabled
No option Display the CSM module version number.
Upon Request
Configure legacy Gate A behavior.
Always
Force BIOS
Enable or disable option ROM message.
Keep Current
Immediate Select the BIOS reaction on INT19 trapping by option ROM:
Postponed 'Immediate' - Executes the trap immediately.
'Postpone' - Executes the trap during legacy boot.
UEFI and Legacy Control which devices and boot loaders the system should boot to.
Legacy Only
UEFI Only
Do not launch Control the execution of UEFI and legacy network option ROMs.
UEFI only
Legacy only
Do not launch Control the execution of UEFI and legacy storage option ROMs.
UEFI only
Legacy only
Do not launch Control the execution of UEFI and legacy video option ROMs
UEFI only
Legacy only
UEFI only Control the execution of UEFI and legacy option ROMs for PCI devices different to network, video and storage.
Legacy only
