Feature
Passive Trip Point
Note
The conga-TCA3 does not support active trip point.
10.4.19

IDE Configuration Submenu

Feature
Serial-ATA (SATA)
SATA Test Mode
SATA Speed Support
SATA ODD Port
SATA Mode
Serial-ATA Port 0
SATA Port 0 Hot Plug
Serial-ATA Port 1
Copyright © 2014 congatec AG
Options Description
110 C Select the temperature for the ACPI passive trip point.
Note: The operating system will throttle the CPU when the selected temperature is reached.
105 C
100 C
95 C
90 C
85 C
79 C
71 C
63 C
55 C
47 C
39 C
31 C
23 C
15 C
Options Description
Enabled Enable or disable the onboard SATA controller.
Disabled
Enabled Enable this feature for verification measurements only.
Disabled
Gen1 Displays the maximum SATA speed supported by the controller.
Gen2
Port 0 ODD Select which SATA port is ODD.
Port 1 ODD
No ODD
IDE Mode Select the SATA port mode.
AHCI Mode
Enabled Enable or disable the SATA port 0.
Disabled
Disabled Enable this feature if you need hot plug support at SATA port 0.
Enabled Note: This feature is not available in native IDE mode.
Enabled
Enable or disable the SATA port 1.
Disabled
