Table 13 Connector C-D Pinout - Congatec COM Express conga-TCA3 User Manual

Table 13 Connector C–D Pinout
Pin Row C
C1 GND (FIXED)
C2 GND
C3 USB_SSRX0-
C4 USB_SSRX0+
C5 GND
C6 USB_SSRX1- (*)
C7 USB_SSRX1+ (*)
C8 GND
C9 USB_SSRX2- (*)
C10 USB_SSRX2+ (*)
C11 GND (FIXED)
C12 USB_SSRX3- (*)
C13 USB_SSRX3+ (*)
C14 GND
C15 DDI1_PAIR6+ (*)
C16 DDI1_PAIR6- (*)
C17 RSVD
C18 RSVD
C19 PCIE_RX6+ (*)
C20 PCIE_RX6- (*)
C21 GND (FIXED)
C22 PCIE_RX7+ (*)
C23 PCIE_RX7- (*)
C24 DDI1_HPD
C25 DDI1_PAIR4+ (*)
C26 DDI1_PAIR4- (*)
C27 RSVD
C28 RSVD
C29 DDI1_PAIR5+ (*)
C30 DDI1_PAIR5- (*)
C31 GND (FIXED)
C32 DDI2_CTRLCLK_AUX+
Copyright © 2014 congatec AG
Pin Row D Pin
D1 GND (FIXED) C56
D2 GND C57
D3 USB_SSTX0- C58
D4 USB_SSTX0+ C59
D5 GND C60
D6 USB_SSTX1- (*) C61
D7 USB_SSTX1+ (*) C62
D8 GND C63
D9 USB_SSTX2- (*) C64
D10 USB_SSTX2+ (*) C65
D11 GND (FIXED) C66
D12 USB_SSTX3- (*) C67
D13 USB_SSTX3+ (*) C68
D14 GND C69
D15 DDI1_CTRLCLK_AUX+ C70
D16 DDI1_CTRLDATA_AUX- C71
D17 RSVD C72
D18 RSVD C73
D19 PCIE_TX6+ (*) C74
D20 PCIE_TX6- (*) C75
D21 GND (FIXED) C76
D22 PCIE_TX7+ (*) C77
D23 PCIE_TX7- (*) C78
D24 RSVD C79
D25 RSVD C80
D26 DDI1_PAIR0+ C81
D27 DDI1_PAIR0- C82
D28 RSVD C83
D29 DDI1_PAIR1+ C84
D30 DDI1_PAIR1- C85
D31 GND (FIXED) C86
D32 DDI1_PAIR2+ C87
Row C Pin Row D
PEG_RX1- (*) D56 PEG_TX1- (*)
TYPE1# D57 TYPE2#
PEG_RX2+ (*) D58 PEG_TX2+ (*)
PEG_RX2- (*) D59 PEG_TX2- (*)
GND (FIXED) D60 GND (FIXED)
PEG_RX3+ (*) D61 PEG_TX3+ (*)
PEG_RX3- (*) D62 PEG_TX3- (*)
RSVD D63 RSVD
RSVD D64 RSVD
PEG_RX4+ (*) D65 PEG_TX4+ (*)
PEG_RX4- (*) D66 PEG_TX4- (*)
RSVD D67 GND
PEG_RX5+ (*) D68 PEG_TX5+ (*)
PEG_RX5- (*) D69 PEG_TX5- (*)
GND (FIXED) D70 GND (FIXED)
PEG_RX6+ (*) D71 PEG_TX6+ (*)
PEG_RX6- (*) D72 PEG_TX6- (*)
GND D73 GND
PEG_RX7+ (*) D74 PEG_TX7+ (*)
PEG_RX7- (*) D75 PEG_TX7- (*)
GND D76 GND
RSVD D77 RSVD
PEG_RX8+ (*) D78 PEG_TX8+ (*)
PEG_RX8- (*) D79 PEG_TX8- (*)
GND (FIXED) D80 GND (FIXED)
PEG_RX9+ (*) D81 PEG_TX9+ (*)
PEG_RX9- (*) D82 PEG_TX9- (*)
RSVD D83 RSVD
GND D84 GND
PEG_RX10+ (*) D85 PEG_TX10+ (*)
PEG_RX10- (*) D86 PEG_TX10- (*)
GND D87 GND
TA30m16 41/95
