Feature
SATA Port 1 Hot Plug
SATA Port 0 Information
SATA Port 1 Information
10.4.20

Miscellaneous Configuration Submenu

Feature
High Precision Timer
Boot Timer with HPET Timer
PCI Express Dynamic Clock
Gating
10.4.21

SCC Configuration Submenu

Feature
SCC Device Mode
SCC eMMC Support
SCC 4.5 DDR50 eMMC Support
SCC 4.5 HS200 eMMC Support
eMMC Secure Erase
SCC SD Card Support
SDR25 Support for SD Card
DDR50 Support for SD Card
Copyright © 2014 congatec AG
Options Description
Disabled Enable this feature if you need hot plug support at SATA port 1.
Note: This feature is not available in native IDE mode.
Enabled
No Option Displays information of device detected at SATA port 0.
No Option Displays information of device detected at SATA port 1.
Options Description
Enabled
Enable or disable the high precision event timer.
Disabled
Enabled Enable this feature to allow boot timer calculation with the high precision event timer.
Disabled
Enabled Enable or disable dynamic clock gating.
Disabled
Options Description
ACPI Mode Select the storage control cluster working mode.
PCI Mode
Enable eMMC 4.5 Support Configure SCC eMMC support mode.
Enable eMMC 4.41 Support
eMMC AUTO MODE
Disable
Enabled Enable or disable DDR50 eMMC support.
Disabled
Enabled Enable or disable HS200 eMMC support.
Disabled
Enabled Enable or disable eMMC secure erase support.
Disabled
Enabled Enable or disable storage control cluster SD card support.
Disabled
Enabled Enable or disable SDR25 support for SD card.
Disabled
Enabled Enable or disable DDR50 support for SD card.
Disabled
