Gigabit Ethernet Pin # Description
GBE0_LINK# A8 Gigabit Ethernet Controller 0 link indicator, active low
GBE0_LINK100# A4 Gigabit Ethernet Controller 0 100Mbit/sec link indicator, active low
GBE0_LINK1000# A5 Gigabit Ethernet Controller 0 1000Mbit/sec link indicator, active low
GBE0_CTREF A14 Reference voltage for Carrier Board Ethernet channel 0 magnetics center tap. The reference
voltage is determined by the requirements of the module PHY and may be as low as 0V and
as high as 3.3V. The reference voltage output shall be current limited on the module. In the
case in which the reference is shorted to ground, the current shall be limited to 250mA or less.
Table 25 Intel High Definition Audio Link Signals Descriptions
®
Signal Pin # Description
AC/HDA_RST# A30 Intel
external codec(s)
AC/HDA_SYNC A29 Intel
to the codec(s). It is also used to encode the stream number
AC/HDA_BITCLK A32 Intel
serial data clock generated by the Intel
AC/HDA_SDOUT A33 Intel
output to the codec(s). This serial output is double-pumped for a bit rate of 48
Mb/s for Intel
AC/HDA_SDIN[1:0] B29-B30 Intel
data inputs from the two codecs. The serial input is single-pumped for a bit rate
of 24 Mb/s for Intel
Table 26 ExpressCard Support Pins Descriptions
Signal Pin #
EXCD0_CPPE# A49
EXCD0_PERST# A48
EXCD1_CPPE# B48
EXCD1_PERST# B47
Copyright © 2014 congatec AG
® High Definition Audio Reset: This signal is the master hardware reset to
® High Definition Audio Sync: This signal is a 48 kHz fixed rate sample sync
® High Definition Audio Bit Clock Output: This signal is a 24.000MHz
® High Definition Audio controller
® High Definition Audio Serial Data Out: This signal is the serial TDM data
High Definition Audio
®
® High Definition Audio Serial Data In [1:0]: These signals are serial TDM
High Definition Audio
®
Description
ExpressCard 0 capable card request
ExpressCard 0 Reset
ExpressCard 1 capable card request
ExpressCard 1 Reset
I/O
O 3.3V
O 3.3V
O 3.3V
O 3.3V
I 3.3V
I/O PU/PD Comment
I 3.3V PU 10k 3.3V
O 3.3V PU 10k 3.3V
I 3.3V PU 10k 3.3V
O 3.3V PU 10k 3.3V
TA30m16
I/O PU/PD Comment
O 3.3VSB
O 3.3VSB
O 3.3VSB
Not connected
PU/PD Comment
AC'97 codecs are not supported
AC'97 codecs are not supported
AC'97 codecs are not supported
AC'97 codecs are not supported
100k PD AC'97 codecs are not supported
AC/HDA_SDIN2 is not supported
