Table 17 HDMI Signal Descriptions
Signal Pin # Description
TMDS1_CLK + D36 TMDS Clock output differential pair
TMDS1_CLK - D37 Multiplexed with DDI1_PAIR3+ and DDI1_PAIR3-
TMDS1_DATA0+ D32 TMDS differential pair
TMDS1_DATA0- D33 Multiplexed with DDI1_PAIR2+ and DDI1_PAIR2-
TMDS1_DATA1+ D29 TMDS differential pair
TMDS1_DATA1- D30 Multiplexed with DDI1_PAIR1+ and DDI1_PAIR1-
TMDS1_DATA2+ D26 TMDS differential pair
TMDS1_DATA2- D27 Multiplexed with DDI1_PAIR0+ and DDI1_PAIR0-
HDMI1_HPD C24 TMDS Hot-plug detect
Multiplexed with DDI1_HPD
HDMI1_CTRLCLK D15 TMDS I
Multiplexed with DDI1_CTRLCLK_AUX+
HDMI1_CTRLDATA D16 TMDS I
Multiplexed with DDI1_CTRLDATA_AUX-
TMDS2_CLK + D49 TMDS Clock output differential pair
TMDS2_CLK - D50 Multiplexed with DDI2_PAIR3+ and DDI2_PAIR3-
TMDS2_DATA0+ D46 TMDS differential pair
TMDS2_DATA0- D47 Multiplexed with DDI2_PAIR2+ and DDI2_PAIR2-
TMDS2_DATA1+ D42 TMDS differential pair
TMDS2_DATA1- D43 Multiplexed with DDI2_PAIR1+ and DDI2_PAIR1-
TMDS2_DATA2+ D39 TMDS differential pair
TMDS2_DATA2- D40 Multiplexed with DDI2_PAIR0+ and DDI2_PAIR0-
HDMI2_HPD D44 TMDS Hot-plug detect
Multiplexed with DDI2_HPD
HDMI2_CTRLCLK C32 TMDS I
Multiplexed with DDI2_CTRLCLK_AUX+
HDM12_CTRLDATA C33 TMDS I
Multiplexed with DDI2_CTRLDATA_AUX-
TMDS3_CLK + C49 TMDS Clock output differential pair
TMDS3_CLK - C50 Multiplexed with DDI3_PAIR3+ and DDI3_PAIR3-
TMDS3_DATA0+ C46 TMDS differential pair
TMDS3_DATA0- C47 Multiplexed with DDI3_PAIR2+ and DDI3_PAIR2-
TMDS3_DATA1+ C42 TMDS differential pair
TMDS3_DATA1- C43 Multiplexed with DDI3_PAIR1+ and DDI3_PAIR1-
TMDS3_DATA2+ C39 TMDS differential pair
TMDS3_DATA2- C40 Multiplexed with DDI3_PAIR0+ and DDI3_PAIR0-
Copyright © 2014 congatec AG
C Control Clock
2
2 C Control Data
C Control Clock
2
C Control Data
2
I/O PU/PD Comment
O PCIE
O PCIE
O PCIE
O PCIE
I PCIE PD 1M
I/O OD PU 3.0k
3.3V 3.3V
I/O OD PU 3.0k Boot strap signal (see note below).
3.3V 3.3V Enable strap is already populated
O PCIE
O PCIE
O PCIE
O PCIE
I PCIE PD 1M
I/O OD PU 3.0k
3.3V 3.3V
I/O OD PU 3.0k Boot strap signal (see note below).
3.3V 3.3V Enable strap is already populated
O PCIE Not supported
O PCIE Not supported
O PCIE Not supported
O PCIE Not supported
TA30m16 48/95
