Feature
Recorder Mode
Resolution 100x31
Legacy OS Redirection
Resolution
Putty KeyPad
10.4.15.2 Console Redirection Settings Out-of-Band Management Submenu
Feature
Terminal Type
Bits Per Second
Data Bits
Parity
Stop Bits
10.4.16

CPU Configuration Submenu

Feature
►Socket 0 CPU Information
►CPU Thermal Configuration
CPU Speed
64-bit
Copyright © 2014 congatec AG
Options Description
Disabled Enable this feature to only send text output over the terminal.
Note: This feature is helpful to capture and record terminal data.
Enabled
Disabled Enable or disable extended terminal resolution.
Enabled
80x24 Select the number of rows and columns for the legacy operating system redirection.
80x25
VT100 Select the function key and keypad for Putty.
LINUX
XTERMR6
SCO
ESCN
VT400
Options Description
VT100 Set the terminal type.
VT100+
VT-UTF8
ANSI
9600 Set the baud rate.
19200
38400
57600
115200
8 Set the number of data bits.
None
1 Set the number of stop bits.
Options Description

Submenu

Opens the socket specific CPU information.
Submenu Opens the CPU thermal configuration options.
No option Displays the CPU clock frequency.
No option Displays whether 64-bit is supported.
TA30m16 77/95
