10.4.31.1 NIC Configuration Submenu

Feature
Link Speed
Wake on LAN
10.4.32

Driver Health Submenu

Feature
►Intel
® PRO/1000
10.5

Chipset Setup

Select the Boot tab from the setup menu to enter the Boot setup screen.
10.5.1

North Bridge Submenu

Feature
Memory Information
Total Memory
Memory Slot 0
Memory Slot 1
Max TOLUD
Aperture Size
PAVC
Copyright © 2014 congatec AG
Options Description
Auto Negotiated
Select the port speed for the selected boot protocol.
10 Mbps Half
10 Mbps Full
100 Mbps Half
100 Mbps Full
Disabled Enable or disable the Wake on LAN (WOL) feature
Enabled
Options Description
No option Displays health status of the drivers/controllers connected to the system.
Options Description
No option Displays total amount of memory detected by the system
No option Displays memory detected by the system on slot 0.
No option Displays memory detected by the system on slot 1
Dynamic
Select the maximum Top of Low Usable DRAM (TOLUD).
2 GB
2.25 GB
2.5 GB
2.75 GB
3 GB
128MB, 256MB, 512MB Set the aperture size.
Enable Enable or disable Protected Audio Video Control (PAVC).
Disable
