10.4.9

SIO Submenu

Feature
AMI SIO Driver Version
►Serial Port 1
►Serial Port 2
►Parallel Port
►PS2 Controller (KB&MS)
Note
This setup menu is only available if an external Winbond W83627 Super I/O has been implemented on the carrier board.
10.4.10

Serial Port 1 Submenu

Feature
Use this Device
Logical Device Settings
Possible
10.4.11

Serial Port 2 Submenu

Feature
Use this Device
Logical Device Settings
Possible
Copyright © 2014 congatec AG
Options Description
No option
No option Opens 'Serial Port 1' submenu.
No option Opens 'Serial Port 2' submenu.
No option Opens 'Parallel Port' submenu.
No option Opens 'PS2 Controller' submenu.
Options
Enable
Disable
No option
Use Automatic Settings
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA;
IO=2F8; IRQ=3,4,5,7,9,10,11,12; DMA;
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA;
IO=3E8; IRQ=3,4,5,7,9,10,11,12; DMA;
Options
Enable
Disable
No option
Use Automatic Settings
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=2F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=3E8; IRQ=3,4,5,7,9,10,11,12; DMA
Description
Enable or disable logical device.
Displays logical device settings.
Select the configuration for serial port 1.
Description
Enable or disable logical device.
Displays logical device settings.
Select the configuration for serial port 2.
