Signal Pin # Description
SLEEP# B103 Sleep button. Used by the ACPI operating system to bring the system to sleep state or to wake it
up again.
Note: For proper detection, assert a pulse width of at least 16 ms.
Table 32 General Purpose Serial Interface Signal Descriptions
Signal Pin # Description
SER0_TX 1 A98 General purpose serial port transmitter
SER1_TX A101 General purpose serial port transmitter
1
SER0_RX 1 A99 General purpose serial port receiver
SER1_RX A102 General purpose serial port receiver
1
Note
1. Pins are protected on the module by a series schotty diode. Therefore, pull-down resistor is required on the carrier board for proper logic
level.
Table 33 Module Type Definition Signal Description
Signal Pin # Description
TYPE0# C54 The TYPE pins indicate to the Carrier Board the Pin-out Type that is implemented on the module. The pins are tied on
TYPE1# C57 the module to either ground (GND) or are no-connects (NC). For Pinout Type 1, these pins are don't care (X).
TYPE2# D57
TYPE2#
X
NC
NC
NC
NC
GND
The Carrier Board should implement combinatorial logic that monitors the module TYPE pins and keeps power off
(e.g deactivates the ATX_ON signal for an ATX power supply) if an incompatible module pin-out type is detected.
The Carrier Board logic may also implement a fault indicator such as an LED.
Copyright © 2014 congatec AG
TYPE1# TYPE0#
X X
NC NC
NC GND
GND NC
GND GND
NC NC
I/O
I OD 3.3V
I/O PU/PD
O 3.3V
O 3.3V
I 3.3V 43.2k 3.3V
I 3.3V 43.2k 3.3V
Pinout Type 1
Pinout Type 2
Pinout Type 3 (no IDE)
Pinout Type 4 (no PCI)
Pinout Type 5 (no IDE, no PCI)
Pinout Type 6 (no IDE, no PCI)
TA30m16
PU/PD Comment
PU 10k
3.3VSB
Comment
I/O Comment
PDS TYPE[0:2]# signals are
available on all modules
following the Type 2-6
Pinout standard.
The conga-TCA3 is
based on the COM
Express Type 6 pinout
therefore the pins 0 and
1 are not connected and
pin 2 is connected to
GND.
