10.4.12

Parallel Port Submenu

Feature
Use this Device
Logical Device Settings
Possible
10.4.13 PS2 Controller (KB&MS) Submenu
Feature
Use this Device
Logical Device Settings
Possible
10.4.14 Intel Smart Connect Technology Submenu
®
Feature
ISCT Support
ISCT Notification Control
ISCT WLAN Power Control
ISCT WWAN Power Control
ISCT Sleep Duration Value Format
ISCT RF Kill Switch Type
ISCT RTC Timer Support
Copyright © 2014 congatec AG
Options
Enable
Disable
No option
Use Automatic Settings
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=2F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=3F8; IRQ=3,4,5,7,9,10,11,12; DMA
IO=3E8; IRQ=3,4,5,7,9,10,11,12; DMA
Options
Enable
Disable
No option
Use Automatic Settings
IO=60h; IO=64h; IRQ=1
Options Description
Disabled Enable or disable Intel
Enabled Note: If this setup node is set to disabled, all the other nodes will be invisible.
Disabled Enable or disable ISCT notification control.
Enabled
Disabled Enable or disable ISCT WLAN power control.
Enabled
Disabled Enable or disable ISCT WWAN power control
Enabled
Duration in Seconds Set the ISCT sleep duration in seconds.
Software Set the ISCT RF kill switch type.
Hardware
Disabled Enable or disable ISCT RTC timer.
Enabled
Description
Enable or disable logical device.
Displays logical device settings.
Select configuration for parallel port.
Description
Enable or disable logical device.
Displays logical device settings.
Select configuration for PS2.
Smart Connection Support (ISCT).
®
