Specifications
Power (hp SIBA
[kW]) Type RK1
0.34–0.5 5017906-005
[0.25–0.37]
0.75–1.5 5017906-010
[0.55–1.1]
2 [1.5] 5017906-016
3 [2.2] 5017906-020
4 [3.0] 5017906-025
5 [3.7] 5012406-032
7.5–10 5014006-050
[5.5–7.5]
15 [11] 5014006-063
20 [15] 5014006-080
25–30 2028220-125
[18.5–22]
40 [30] 2028220-150
50 [37] 2028220-200
60 [45] 2028220-250
Table 10.19 3 x 200–240 V, Frame Sizes A, B and C
Power (hp Bussmann
[kW]) 2)
Type JFHR2
0.34–0.5 FWX-5
[0.25–0.37]
0.75–1.5 FWX-10
[0.55–1.1]
2 [1.5] FWX-15
3 [2.2] FWX-20
4 [3.0] FWX-25
5 [3.7] FWX-30
7.5–10 FWX-50
[5.5–7.5]
15 [11] FWX-60
20 [15] FWX-80
25–30 FWX-125
[18.5–22]
40 [30] FWX-150
50 [37] FWX-200
60 [45] FWX-250
Table 10.20 3 x 200–240 V, Frame Sizes A, B and C
1) KTS fuses from Bussmann may substitute for KTN for 240 V adjustable frequency drives.
2) FWH fuses from Bussmann may substitute for FWX for 240 V adjustable frequency drives.
3) A6KR fuses from FERRAZ SHAWMUT may substitute for A2KR for 240 V adjustable frequency drives.
4) A50X fuses from FERRAZ SHAWMUT may substitute for A25X for 240 V adjustable frequency drives.
®
VLT AQUA Drive
Instruction Manual
Recommended max. fuse
Littel fuse
Type RK1
KLN-R-05
KLN-R-10
KLN-R-15
KLN-R-20
KLN-R-25
KLN-R-30
KLN-R-50
KLN-R-60
KLN-R-80
KLN-R-125
KLN-R-150
KLN-R-200
KLN-R-250
Recommended max. fuse
Littel fuse
JFHR2
-
-
-
-
-
-
-
-
-
-
L25S-150
L25S-200
L25S-250
®
