Parameter
6-15 Terminal 53
High Ref./Feedb.
Value
6-50 Terminal 42
Output
14-20 Reset Mode
22-85 Speed at
Design Point [RPM]
See Note 3
22-86 Speed at
5 5
Design Point [Hz]
Table 5.1 International/North American Default
Parameter Settings
Note 1: 1-20 Motor Power [kW] is only visible when 0-03 Regional
Settings is set to [0] International.
Note 2: 1-21 Motor Power [HP], is only visible when 0-03 Regional
Settings is set to [1] North America.
Note 3: This parameter is only visible when 0-02 Motor Speed Unit is
set to [0] RPM.
Note 4: This parameter is only visible when 0-02 Motor Speed Unit is
set to [1] Hz.
Changes made to default settings are stored and available
for viewing in the quick menu along with any
programming entered into parameters.
1. Press [Quick Menu].
2. Scroll to Q5 Changes Made and press [OK].
Figure 5.12 Quick Menus
5-4
®
VLT
Instruction Manual
International North American
Default Parameter Default Parameter
Value Value
50 60
100 Speed 4–20 mA
Automatic reset x 10 Infinite auto reset
1500 RPM 1800 RPM
50 Hz 60 Hz
25.9% 0.00A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
MG20M922 - VLT
AQUA Drive
3. Select Q5-2 Since Factory Setting to view all
programming changes or Q5-1 Last 10 Changes
for the most recent.
Figure 5.13 Changes Made

5.5 Parameter Menu Structure

Establishing the correct programming for applications
often requires setting functions in several related
parameters. These parameter settings provide the
adjustable frequency drive with system details it needs to
operate properly. System details may include such things
as input and output signal types, programming terminals,
minimum and maximum signal ranges, custom displays,
automatic restart, and other features.
•
See the LCP display to view detailed parameter
programming and setting options.
•
Press [Info] in any menu location to view
additional details for that function.
•
Press and hold [Main Menu] to enter a parameter
number for direct access to that parameter
•
Details for common application set-ups are
1(1)
provided in 6 Application Set-up Examples.
®
is a registered Danfoss trademark
25.9% 0.00A
Changes Made
Q5-1 Last 10 Changes
Q5-2 Since Factory Setti...
Q5-3 Input Assignments
1(1)
Q5
