Specifications
Line Power Supply 3 x 200–240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
Typical Shaft Output [HP] at 208 V
IP20/NEMA Chassis *
IP21/NEMA 1
IP55/NEMA 12
IP66
Output current
Continuous (3 x 200–240 V) [A]
Intermittent (3 x 200–240 V) [A]
Continuous kVA (208 V AC) [kVA]
Max. input current
Continuous (3 x 200–240 V) [A]
Intermittent (3 x 200–240 V) [A]
Max. pre-fuses 1) [A]
Additional specifications
Estimated power loss at rated
4)
max. load [W]
Max. cable size (line power, motor,
brake)
2 2)
[mm ]/(AWG)
Weight enclosure IP20 (lb [kg])
Weight enclosure IP21 (lb [kg])
Weight enclosure IP55 (lb [kg])
Weight enclosure IP66 (lb [kg])
Efficiency 3)
Table 10.3 Line Power Supply 3 x 200–240 V AC - Normal Overload 110% for 1 Minute
*
B3+4 and C3+4 may be converted to IP21 using a conversion kit
(contact Danfoss)
®
VLT AQUA Drive
Instruction Manual
P5K5 P7K5 P11K
5.5 7.5 11
7.5 10 15
B3 B3 B3
B1 B1 B1
B1 B1 B1
B1 B1 B1
24.2 30.8 46.2
26.6 33.9 50.8
8.7 11.1 16.6
22.0 28.0 42.0
24.2 30.8 46.2
63 63 63
269 310 447
[10]/(7)
26.46 [12] 26.46 [12] 26.46 [12]
50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65]
50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65]
50.71 [23] 50.71 [23] 50.71 [23] 59.53 [27] 99.21 [45] 99.21 [45] 143.3 [65]
0.96 0.96 0.96
®
MG20M922 - VLT is a registered Danfoss trademark
P15K P18K P22K
15 18.5 22
20 25 30
B4 B4 C3
B2 C1 C1
B2 C1 C1
B2 C1 C1
59.4 74.8 88.0
65.3 82.3 96.8
21.4 26.9 31.7
54.0 68.0 80.0
59.4 74.8 88.0
80 125 125
602 737 845
[35]/(2) [50]/(1/0)
51.81 51.81
77.16 [35] 77.16 [35] 110.23 [50]
[23.5] [23.5]
0.96 0.96 0.97
P30K P37K P45K
30 37 45
40 50 60
C3 C4 C4
C1 C2 C2
C1 C2 C2
C1 C2 C2
115 143 170
127 157 187
41.4 51.5 61.2
104.0 130.0 154.0
114.0 143.0 169.0
160 200 250
1140 1353 1636
[120]/
[95]/(4/0) (250
MCM)
110.23
[50]
143.3 [65] 143.3 [65]
143.3 [65] 143.3 [65]
143.3 [65] 143.3 [65]
0.97 0.97 0.97
