Specifications
Enclosure
A3
B2
C2
C3
D
Table 10.15 525–690 V, Frame Sizes A, C and D (non-UL fuses)
10 10
10-20
®
VLT
Instruction Manual
Power (hp [kW]) Recommended fuse size
1.5 [1.1] gG-6
2 [1.5] gG-6
3 [2.2] gG-6
4 [3] gG-10
5 [4] gG-10
7.5 [5.5] gG-16
10 [7.5] gG-16
15 [11] gG-25
20 [15] gG-25
25 [18] gG-32
30 [22] gG-32
40 [30] gG-40
50 [37] gG-63
60 [45] gG-63
75 [55] gG-80
100 [75] gG-100
50 [37] gG-100
60 [45] gG-125
50 [37] gG-125
60 [45] gG-160
75–100 [55–75] gG-200
125 [90] aR-250
MG20M922 - VLT
AQUA Drive
Recommended max. fuse
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-25
gG-63
gG-63
gG-80
gG-100
gG-125
gG-160
gG-125
gG-160
gG-125
gG-160
gG-200
aR-250
®
is a registered Danfoss trademark
Recommended circuit Max trip level[A]
breaker
Danfoss
CTI25M 10-16 16
CTI25M 10-16 16
CTI25M 10-16 16
CTI25M 10-16 16
CTI25M 10-16 16
CTI25M 10-16 16
CTI25M 10-16 16
