Specifications
10.1.5 Line Power Supply 3 x 525–600 V AC
Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
IP20/NEMA Chassis
IP21/NEMA 1
IP55/NEMA 12
IP66
Output current
Continuous (3 x 525–550 V) [A]
Intermittent (3 x 525–550 V) [A]
Continuous (3 x 525–600 V) [A]
Intermittent (3 x 525–600 V) [A]
Continuous kVA (525 V AC) [kVA]
Continuous kVA (575 V AC) [kVA]
Max. input current
Continuous (3 x 525–600 V) [A]
Intermittent (3 x 525–600 V) [A]
1)
Max. pre-fuses [A]
Additional specifications
Estimated power loss at rated max. load [W]
Max. cable size (line power, motor, brake)
2 2)
[mm ]/(AWG)
Weight enclosure IP20 (lb [kg])
Efficiency 4)
Table 10.7 Line Power Supply 3 x 525–600 V AC
1)
For type of fuse, see 10.3.2 Fuse Tables
2)
American Wire Gauge
3) Measured using 16 ft [5 m] shielded motor cables at rated load
and rated frequency
4) The typical power loss is at normal load conditions and expected
± 15% (tolerance relates to variety in voltage and cable
to be within
conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line).
Lower efficiency motors will also add to the power loss in the
adjustable frequency drive and vice versa.
®
VLT AQUA Drive
Instruction Manual
PK75 P1K1 P1K5
0.75 1.1
A2 A2
A2 A2
A5 A5
A5 A5
1.8 2.6
2.9
1.7 2.4
2.6
1.7 2.5
1.7 2.4
1.7 2.4
2.7
10 10
4) 35 50
14.33 14.33 14.33
[6.5] [6.5] [6.5]
0.97 0.97 0.97
If the switching frequency is raised from nominal, the power losses
may rise significantly.
LCP and typical control card power consumption values are included.
Further options and customer load may add up to 30 Watts to the
losses. (Though typically only 4 W extra for a fully loaded control
card or options for slot A or slot B, each).
Although measurements are made with state-of-the-art equipment,
some measurement inaccuracy must be allowed for (
5)
Motor and line cable: 300 MCM/150 mm
®
MG20M922 - VLT is a registered Danfoss trademark
P2K2 P3K0 P4K0
1.5 2.2 3 4
A2 A2 A2 A2
A2 A2 A2 A2
A5 A5 A5 A5
A5 A5 A5 A5
2.9 4.1 5.2 6.4
3.2 4.5 5.7 7.0
2.7 3.9 4.9 6.1
3.0 4.3 5.4 6.7
2.8 3.9 5.0 6.1
2.7 3.9 4.9 6.1
2.7 4.1 5.2 5.8
3.0 4.5 5.7 6.4
10 20 20 20
65 92 122 145
[0.2–4]/(24–10)
14.33 14.33 14.33
[6.5] [6.5] [6.5]
0.97 0.97 0.97
P5K5 P7K5 P11K
5.5 7.5 11
A3 A3 B3
A3 A3 B1
A5 A5 B1
A5 A5 B1
9.5 11.5 19
10.5 12.7 21
9.0 11.0 18
9.9 12.1 20
9.0 11.0 18.1
9.0 11.0 17.9
8.6 10.4 17.2
9.5 11.5 19
32 32 40
195 261 225
[16]/(6)
14.55 14.55 26.46
[6.6] [6.6] [12]
0.97 0.97 0.98
10
± 5%).
2
10-7
10
