Specifications

10.3.3 UL Compliance

Fuses or circuit breakers are mandatory to comply with UL for NEC 2009. We recommend using a selection of the following.
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical) with the following
voltage
•
240 V
•
480 V
•
600 V
•
690 V
depending on the drive voltage rating. With the proper fusing, the drive Short Circuit Current Rating (SCCR) is 100,000 Arms.
Power Max. prefuse Buss-
(hp [kW]) size [A] mann
JFHR2
FWX-1
1.5 [1.1] 15 5
FWX-2
2 [1.5] 20 0
FWX-3
3 [2.2] 30* 0
FWX-3
4 [3.0] 35 5
FWX-5
5 [3.7] 50 0
FWX-6
7.5 [5.5] 60** 0
FWX-8
10 [7.5] 80 0
FWX-1
20 [15] 150 50
FWX-2
30 [22] 200 00
Table 10.16 1 x 200–240 V
* Siba allowed up to 32 A
** Siba allowed up to 63 A
®
VLT AQUA Drive
Instruction Manual
Recommended max. fuse
Buss- Buss- Buss- Buss- Buss-
mann mann mann mann mann
RK1 J T CC
KTN- FNQ-
R15 JKS-15 JJN-15 R-15
KTN- FNQ-
R20 JKS-20 JJN-20 R-20
KTN- FNQ-
R30 JKS-30 JJN-30 R-30
KTN-
R35 JKS-35 JJN-35
KTN-
R50 JKS-50 JJN-50
KTN-
R60 JKS-60 JJN-60
KTN-
R80 JKS-80 JJN-80
KTN- JKS-15 JJN-15
R150 0 0
KTN- JKS-20 JJN-20
R200 0 0
®
MG20M922 - VLT is a registered Danfoss trademark
Buss- SIBA Littel
mann RK1 fuse
CC CC RK1
KTK- LP- 501790 KLN-
R-15 CC-15 6-016 R15
KTK- LP- 501790 KLN-
R-20 CC-20 6-020 R20
KTK- LP- 501240 KLN-
R-30 CC-30 6-032 R30
KLN-
--- R35
501400 KLN-
6-050 R50
501400 KLN-
6-063 R60
501400 KLN-
6-080 R80
202822 KLN-
0-150 R150
202822 KLN-
0-200 R200
Ferraz- Ferraz- Ferraz-
Shawmut Shawmut Shawmut
CC RK1 J
ATM-R15 A2K-15R HSJ15
ATM-R20 A2K-20R HSJ20
ATM-R30 A2K-30R HSJ30
--- A2K-35R HSJ35
--- A2K-50R HSJ50
--- A2K-60R HSJ60
--- A2K-80R HSJ80
A2K-150R HSJ150
A2K-200R HSJ200
