7.1.3 Supported video formats

Videos can be displayed in web mode (see
are supported when embedding videos into a web-based HMI application:
• WebM
• MP4 (H.264)

7.1.4 User agent

For identification purposes, each web browser transmits various information (e.g. browser name, version, operating
system) to the web server providing the HTML page.
As part of the HTTP header, a web browser identifies itself as a user agent. With PPT image version 1.3.0 and
later, the web browser on the Power Panel transmits additional information.
Example: User-Agent: Mozilla/5.0 ...
Description of the Power Panel information:
Identification := BRPanel/<Version> (<Type>;<Orientation>;<Resolution>;<OrderId>)
BRPanel
Identification as B&R panel.
<Version>
Version number of the comment (expression in parentheses), which is primarily used to evaluate the information within the paren-
theses correctly.
Format of <Version>: <Number>.<Number>
<Type>
Name of device family: PPT50, PPC50, etc.
<Orientation>
The orientation of the screen display contains one of the following two values:
landscape
portrait
<Resolution>
Resolution of the device in the format "WIDTHxHEIGHT".
Format of <Resolution>: WIDTHxHEIGHT
WIDTH
HEIGHT
The width and height of the display are output according to the orientation:
<OrderId>
Model number of the Power Panel.

7.2 File formats

7.2.1 PPT image

The PPT image is a compressed image of the PPT system (Power Panel T-Series operating system). The PPT
image is a package and consists of the following files:
File
PPT80Image.img.gz
PPT80Image.info
Information:
During an update, the MD5 checksum determines if the image is free of errors.

7.2.2 System settings

Filename: PPT80Config.xml
The system settings that can be defined by the user on the
file PPT80Config.xml .
When backing up and restoring (see the two service pages
data for the settings is exchanged via an XML file with this name.
Power Panel T80 User's manual V1.03
"Configuring web mode" on page
Landscape
Portrait
Width of the display in pixels.
Height of the display in pixels.
•
Example for landscape format: 1280x800
•
Example for portrait format: 800x1280
Description
Compressed image of the PPT system.
BRPanel/1.0 (PPT50;landscape;1280x800;6PPT50.101E-16B;)
service pages
Backup & Reset
53). The following container formats
are saved on the Power Panel in XML
and Update) the system settings, the
Software
