4.6.2 10.1" Power Panel T80

1 8x retaining clips with torque limiting
2 Anodized front plate E6/C8 (black)
3 Power-coated cover, RAL 9005, fine structure, flat
Dimensions of the installation cutout for this Power Panel variant: 268 ±1 mm x 180 ±1 mm
See also "Installation cutout requirements" on page
Power Panel T80 User's manual V1.03
117
266
2
279
View A
29.
Device description
1
View A
36.5 5.7
3
23
