Spare Parts List - Mecmesin Multitest 0.5d Service And Repair Manual

Multitest 0.5d, 1d & 2.5d
Service and Repair Manual
35.

Spare Parts List

PCB's supplied will not be accepted back for credit due to obvious handling and
storage problems.
Part No.
900-393
900-394
300-163-V01
300-163-V02
300-164-V01
301-032-V01
428-186
325-015
325-008
329-239
432-448
432-449
406-422
406-403
406-569
406-570
300-148-V01
307-044
352-198
352-084
352-086
352-131
352-188
352-189
352-190
352-192
352-193
305-026
331-076
413-052
413-013 /420-020
Req'd
1 PARVALUX 0.5 TO 2.5d SPARES KIT
1 DUNKER 0.5 TO 2.5d SPARES KIT
1 MT-d MOTOR CONTROL ASSY PARVALUX
1 MT MOTOR CONTROL ASSY DUNKER
MT-d FRONT PANEL PCB ASSY – To ensure the correct
1
'readability' a 301-032-V01 is also required.
MT-d LCD MODULE ASSY – To ensure the correct
1
'readability' a 300-164-V01 is also required.
1 MT-d LCD MEMBRANE KEYPAD
MT-d FRONT PANEL c/w 305-026 EMERGENCY STOP BUTTON
1 FUSE pcb 6.3A CERAMIC ANTISURGE
2 FUSE mains inlet 2A 20mm x 5mm T (Time lag).
1 DELTA MAINS INLET FILTER 6A
1 LIMITSWITCH COMPLETE ASSEMBLY Mk1 MT 1-d, Mk2
MT 2.5-d
1 LIMITSWITCH COMPLETE ASSEMBLY Mk1 MT 2.5-d, Mk2
MT 1-d
1 MULTITEST Mk1 MT 1-d, Mk2 MT 2.5-d LIMIT SWITCH ROD
1 MULTITEST Mk1 MT 2.5-d LIMIT SWITCH ROD
1 MULTITEST Mk2 MT 1-d LIMIT SWITCH ROD
1 MULTITEST Mk2 MT 0.5-d LIMIT SWITCH ROD
1 LIMIT SWITCH PCB - ONLY
2 OPTO SWITCH OPB625 (Component of above).
1 LOOM TRANSFORMER ASSY
1 LOOM EARTH FILTER
1 LOOM EARTH REAR PANEL
1 LOOM EARTH LIMIT SWITCH
1 LOOM EMERGENCY STOP (inc E Stop contact block)
1 LOOM SPI
1 LOOM COMMUNICATIONS
1 LOOM FRONT PANEL RS232 (connects between the Front
Panel PCB and the Motor Control PCB)
1 LOOM REAR PANEL RS232 (connects the Motor Control
PCB to the PC socket labelled RS232 on the back of the test
stand.)
1 EMERGENCY STOP BUTTON only (see 352-188)
1 MECHANICAL ROTARY ENCODER (SPEED POT).
1 BLACK ALUMINIUM KNOB (SPEED POT).
2 M4 KNOBLET (The screw is to be supplied with this).
Number 022-005
Issue Number: 08
Description
only supplied affixed to 404-193
Page 56 of 58
