Multitest 0.5d, 1d & 2.5d
Service and Repair Manual
115. Adjust top and bottom (short) locking collars to "Factory" set limits as listed in
the table below. Tighten in position using Loctite 243 on the screwthreads.
Mk 1 Stands
Top Collar
Bottom Collar
Mk 2 Stands
Top Collar
Bottom Collar
Refitting of the Limit Switch
is the reverse of the above procedure
0.5 kN Stands
-
-
50mm
60mm
Number 022-005
Issue Number: 08
114. Withdraw the limit switch/rod
assembly from the test stand
1 kN Stands
65mm
60mm
50mm
60mm
Page 35 of 58
2.5 kN Stands
65mm
50mm
50mm
60mm
