Multitest 0.5dV, 1dV & 2.5dV
Service and Repair Manual

20. Spare Parts List

PCB's supplied will not be accepted back for credit due to obvious handling and
storage problems.
Changes made to this list also need to be incorporated into the Spare Price Parts List
Item Part No.
1 300-200-V01
2 303-049
3 352-191-V01
4 405-016
5 420-242
6 352-188
7 352-198
8 352-233
9 352-234
10 900-418
11 401-032
12 401-031
13 401-027-V01
14 404-206-F04
15 404-205-F04
16 404-149-F04
17 406-568
18 406-567
19 406-421
20 406-570
21 406-569
22 406-422
23 300-148-V01
24 900-419
25 910-419-V01
26 305-026
27 413-013
28 420-020
29 900-075
30 352-084
31 352-086
32 352-131
33 352-232
34 413-021
35 412-023
36 412-067
37 412-068
38 412-036
39 405-016
40 408-253-F98
41 424-107
42 910-427
300-204 VECTOR USB/RJ11 PCBA
325-008 FUSE 2A CERAMIC ANTISURGE 20mm
329-239 DELTA MAINS INLET FILTER 6A
352-205 LOOM DIGITAL I/O, EVENT, AUX
404-726 MULTITEST-DV REAR PANEL
410-557 LABEL I/O PORT
410-835 LABEL -DV USB REAR PANEL
Description
SINGLE MOTOR VIC PCB ASSY
DUNKMOT MT 0.5 1.0 2.5 TMS
MT-d ENCODER LOOM DUNKER
ULTRATEST TOP CAP
SNAP ACTION PLASTIC RIVET
MT-d EMERGENCY STOP LOOM
TRANSFORMER 22V 120VA
DV REAR PNL RJ11 6 WAY LOOM
DV REAR PNL USB 4 WAY LOOM
MULTITEST DV REAR PANEL ASSY
MT 0.5 Mk2 BALLSCREW
MT 1.0 Mk2 BALLSCREW
MT-2.5 Mk2 BALLSCREW
M'TEST 0.5 SHROUD (PAINTED)
M'TEST 1 SHROUD (PAINTED)
M'TEST 2.5 SHROUD (PAINTED)
MT 0.5 Mk2 COLUMN
MT 1.0 Mk2 COLUMN
MT 2.5 Mk2 COLUMN
MT 0.5 Mk2 LIMIT SWITCH ROD
MT 1.0 Mk2 LIMIT SWITCH ROD
MT 2.5 Mk2 LIMIT SWITCH ROD
COMMON LIMIT SWITCH ASSY
DV FRONT PANEL ASSY
DV FRONT PANEL ASSY MK2
EMERGENCY STOP BUTTON
M4 KNOBLET
SCREW CAP HEAD SKT M4x12
MULTITEST MICROSWITCH SUB ASSY
LOOM EARTH FILTER
LOOM EARTH REAR PANEL
LOOM EARTH LIMIT SWITCH
DV 20 WAY FRONT PNL LOOM
RUBBER FOOT
DUST COVER 25 WAY D SOCKET
USB-B PLUG COVER
RJ11 PLUG COVER
RUBBER BLANK GROMMET 20mmDIA
TOP CAP
ANVIL PLATE
BALLSCREW COUPLING
MULTITEST DV REAR PANEL ASSY
Number 022-780
Issue Number: 02
Qty/Assy
1
1
1
1 (supply together with 420-242)
3 (supply together with 405-016)
1 (inc E Stop contact block)
1
1
1
1
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1 Dependant on stand variant
1
(To 05/01/16)
1
1 (From 06/01/16)
1 only (see 352-188)
2 (supply together with 420-020)
2 (supply together with 413-013)
1
1
1
1
1
4
1
1
1
1
1
1
1
(CONSISTS OF:)
1
2
1
1
1
1
1
Page 30 of 32
Notes
