Electrical, Reliability and Radio
Characteristics

6.1. Absolute Maximum Ratings

Absolute maximum ratings for power supply and voltage on digital and analog pins of the module are
listed in the following table.
Table 31: Absolute Maximum Ratings
Parameter
VBAT_RF/VBAT_BB
USB_VBUS
Peak Current of VBAT_BB
Peak Current of VBAT_RF
Voltage at Digital Pins
Voltage at ADC0
Voltage at ADC1
EC25_Hardware_Design
Min.
-0.3
-0.3
0
0
-0.3
0
0
LTE Standard Module Series
EC25 Hardware Design
Max.
4.7
5.5
0.8
1.8
2.3
VBAT_BB
VBAT_BB
Unit
V
V
A
A
V
V
V
