6.2. Power Supply Ratings

Table 32: Power Supply Ratings
Parameter Description
VBAT_BB and
VBAT_RF
VBAT
Voltage drop during
burst transmission
Peak supply current
I (during transmission
VBAT
slot)
USB power supply,
USB_VBUS used for USB
detection

6.3. Operation and Storage Temperatures

The operation and storage temperatures are listed in the following table.
Table 33: Operation and Storage Temperatures
Parameter
Operation Temperature Range
Extended Temperature Range
Storage Temperature Range
NOTES
1)
1. Within operation temperature range, the module is 3GPP compliant.
2)
2. Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, emergency call* (emergency call is not supported on ThreadX
modules), etc. There is no unrecoverable malfunction. There are also no effects on radio spectrum
EC25_Hardware_Design
Conditions
The actual input voltages
must be kept between the
minimum and maximum
values.
Maximum power control
level on EGSM900.
Maximum power control
level on EGSM900.
Min. Typ.
1)
-35 +25
2)
-40
-40
LTE Standard Module Series
EC25 Hardware Design
Min. Typ. Max.
3.3 3.8 4.3
400
1.8 2.0
3.0 5.0 5.25
Max. Unit
+75 ºC
+85 ºC
+90 ºC
Unit
V
mV
A
V
