Table 37: EC25-J Current Consumption
Parameter Description
Sleep state
Idle state
I
VBAT
WCDMA
data transfer
(GNSS OFF)
LTE data
transfer
(GNSS OFF)
EC25_Hardware_Design
Conditions
AT+CFUN=0 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=128 (USB disconnected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=128 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=64 (USB connected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=64 (USB connected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=64 (USB connected)
WCDMA B1 HSDPA @22.30dBm
WCDMA B1 HSUPA @21.98dBm
WCDMA B6 HSDPA @22.32dBm
WCDMA B6 HSUPA @21.78dBm
WCDMA B8 HSDPA @22.17dBm
WCDMA B8 HSUPA @21.98dBm
WCDMA B19 HSDPA @22.44dBm
WCDMA B19 HSUPA @21.82dBm
LTE-FDD B1 @23.13dBm
LTE-FDD B3 @23.07dBm
LTE Standard Module Series
EC25 Hardware Design
Typ.
2.9
4.0
3.5
4.8
4.0
4.9
4.1
29.6
42.7
29.8
41.3
29.9
42.7
823.4
835.2
616.6
621.6
658.3
690.1
615.7
617.2
1075.0
988.5
Unit
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
