Quectel EC25-AUX Hardware Design page 95

Table 42: EC25-EU Current Consumption
Parameter Description
OFF state
Sleep state
I
VBAT
Idle state
GPRS data
transfer
(GNSS OFF)
EC25_Hardware_Design
WCDMA B5 @22.6dBm
Conditions
Power down
AT+CFUN=0 (USB disconnected)
GSM DRX=2 (USB disconnected)
GSM DRX=9 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=128 (USB disconnected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=128 (USB disconnected)
GSM DRX=5 (USB disconnected)
GSM DRX=5 (USB connected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=64 (USB connected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=64 (USB connected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=64 (USB connected)
EGSM900 4DL/1UL @33.23dBm
EGSM900 3DL/2UL @31.96dBm
EGSM900 2DL/3UL @29.73dBm
LTE Standard Module Series
EC25 Hardware Design
561.0
Typ.
11
1.16
2.74
2.0
2.15
1.67
2.60
1.90
2.79
2.00
19.5
29.5
21.0
31.0
20.7
30.8
20.8
32.0
243.0
388.0
453.0
mA
Unit
uA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
94 / 130
