Quectel EC25-AUX Hardware Design page 88

WCDMA
voice call
Table 38: EC25-AU Current Consumption
Parameter Description
OFF state
I
VBAT
Sleep state
EC25_Hardware_Design
LTE-FDD B8 @23.32dBm
LTE-FDD B18 @23.61dBm
LTE-FDD B19 @23.67dBm
LTE-FDD B26 @22.86dBm
LTE-TDD B41 @22.40dBm
WCDMA B1 @23.23dBm
WCDMA B6 @23.02dBm
WCDMA B8 @23.12dBm
WCDMA B19 @22.99dBm
Conditions
Power down
AT+CFUN=0
AT+CFUN=0 (USB disconnected)
GSM850 DRX=5 (USB disconnected)
EGSM900 DRX=5 (USB disconnected)
DCS1800 DRX=5 (USB disconnected)
PCS1900 DRX=5 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=128 (USB disconnected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=128 (USB disconnected)
LTE Standard Module Series
EC25 Hardware Design
882.3
867.0
911.4
909.6
563.4
964.8
667.9
735.4
664.8
Typ. Unit
11 uA
1.3 mA
1.46 mA
1.8 mA
2.0 mA
1.9 mA
1.9 mA
2.0 mA
1.6 mA
2.2 mA
1.6 mA
2.3 mA
1.6 mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
87 / 130
