6.4. Current Consumption

The values of current consumption are shown below.
Table 34: EC25-E Current Consumption
Parameter Description
OFF state
Sleep state
I
VBAT
Idle state
EC25_Hardware_Design
Conditions
Power down
AT+CFUN=0 (USB disconnected)
GSM DRX=2 (USB disconnected)
GSM DRX=9 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=128 (USB disconnected)
LTE-TDD PF=64 (USB disconnected)
LTE-TDD PF=128 (USB disconnected)
GSM DRX=5 (USB disconnected)
GSM DRX=5 (USB connected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=64 (USB connected)
LTE-FDD PF=64 (USB disconnected)
LTE-FDD PF=64 (USB connected)
LTE Standard Module Series
EC25 Hardware Design
might reduce in their value and
out
Typ.
11
1.16
2.74
2.00
2.15
1.67
2.60
1.90
2.79
2.00
19.5
29.5
21.0
31.0
20.7
30.8
Unit
uA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
