LTE Standard Module Series
EC25 Hardware Design

7.3. Design Effect Drawings of the Module

Figure 47: Top View of the Module
Figure 48: Bottom View of the Module
NOTE
These are renderings of EC25 module. For authentic appearance, please refer to the module that you
receive from Quectel.
EC25_Hardware_Design 119 / 130
