3.2. Pin Assignment

The following figure shows the pin assignment of EC25 module.
1) 1
WAKEUP_IN
2
AP_READY
3
RESERVED
W_DISABLE# 4
1) 5
NET_MODE
6
NET_STATUS
VDD_EXT 7
141
RESERVED
142
RESERVED
8
GND
9
GND
10
USIM_GND
11
DBG_RXD
12
DBG_TXD
13
USIM_PRESENCE
14
USIM_VDD
USIM_DATA 15
USIM_CLK 16
17
USIM_RST
18
RESERVED
NOTES
1)
1. means pins WAKEUP_IN, NET_MODE, WLAN_EN, COEX_UART_RX, COEX_UART_TX,
USB_BOOT and BT_CTS cannot be pulled up before startup.
2)
2. PWRKEY output voltage is 0.8V because of the diode drop in the Qualcomm chipset.
3)
3. means digital audio (PCM) is only supported on Telematics version.
4. Pins 37~40, 118, 127 and 129~139 are used for wireless connectivity interfaces, among which pins
118, 127 and 129~138 are WLAN function pins, and the rest are Bluetooth (BT) function pins. BT
function is under development.
