Reliability, Radio and Electrical
Characteristics

4.1. Electrical Characteristics

The following table shows the absolute maximum ratings.
Table 16: Absolute Maximum Ratings
Parameter
VBAT
VDDIO
Digital I/O Input Voltage
The following table shows the recommended operating conditions of the module.
Table 17: Recommended Operating Conditions
Parameter
VBAT
VDDIO
4.2.

I/O Interface Characteristics

The following table shows the general DC electrical characteristics over recommended operating
conditions (unless otherwise specified).
FC80A_Hardware_Design
Min.
-0.5
-0.5
-0.5
Min. Typ.
3.2 3.3
1.62 1.8/3.3
Wi-Fi&Bluetooth Module Series
Max.
6.0
3.9
3.9
Max.
4.5
3.63
Unit
V
V
V
Unit
V
V
