Quectel EC25-AUX Hardware Design page 111

Table 58: EC25-EU Conducted RF Receiving Sensitivity
Frequency
EGSM900
DCS1800
WCDMA B1
WCDMA B8
LTE-FDD B1 (10MHz)
LTE-FDD B3 (10MHz)
LTE-FDD B7 (10MHz)
LTE-FDD B8 (10MHz)
LTE-FDD B20 (10MHz)
LTE-FDD B28 (10MHz)
LTE-TDD B38 (10MHz)
LTE-TDD B40 (10MHz)
LTE-TDD B41 (10MHz)
Table 59: EC25-EC Conducted RF Receiving Sensitivity
Frequency
EGSM900
DCS1800
WCDMA B1
WCDMA B8
LTE-FDD B1 (10MHz)
LTE-FDD B3 (10MHz)
LTE-FDD B7 (10MHz)
EC25_Hardware_Design
Primary Diversity
-108.5dBm /
-108.5dBm /
-109.5dBm -109.5dBm
-110.0dBm -111.5 dBm
-98.5dBm -99.0dBm
-98.2dBm -99.8dBm
-96.7dBm -98.5dBm
-98.5dBm -100.4dBm
-98.7dBm -100.2dBm
-98.7dBm -100.5dBm
-95.2dBm -97.0dBm
-95.7dBm -98.2dBm
-95.0dBm -97.1dBm
Primary Diversity
-108.8dBm /
-109.0dBm /
-110.5dBm /
-110.5dBm /
-98.0dBm -98.0dBm
-96.5dBm -98.5dBm
-97.0dBm -95.5dBm
LTE Standard Module Series
EC25 Hardware Design
1)
SIMO 3GPP (SIMO)
/ -102.0dBm
/ -102.0dbm
/ -106.7dBm
/ -103.7dBm
-101.7dBm -96.3dBm
-102dBm -93.3dBm
-100.7dBm -94.3dBm
-102.4dBm -93.3dBm
-102.7dBm -93.3dBm
-102.5dBm -94.8dBm
-100.2dBm -96.3dBm
-101.2dBm -96.3dBm
-100.2dBm -94.3dBm
1)
SIMO 3GPP (SIMO)
/ -102.0dBm
/ -102.0dbm
/ -106.7dBm
/ -103.7dBm
-101.0dBm -96.3dBm
-100.0dBm -93.3dBm
-99.5dBm -94.3dBm
110 / 130
