Quectel EC25-AUX Hardware Design page 93

WCDMA data
transfer
(GNSS OFF)
LTE data
transfer
(GNSS OFF)
WCDMA
voice call
Table 41: EC25-AFX Current Consumption
Parameter Description
OFF state
I
VBAT
Sleep state
EC25_Hardware_Design
WCDMA B2 HSDPA @22.63dBm
WCDMA B2 HSUPA @22.49dBm
WCDMA B4 HSDPA @22.45dBm
WCDMA B4 HSUPA @22.57dBm
WCDMA B5 HSDPA @22.49dBm
WCDMA B5 HSUPA @22.43dBm
LTE-FDD B2 @22.92dBm
LTE-FDD B4 @23.12dBm
LTE-FDD B5 @22.98dBm
LTE-FDD B12 @23.42dBm
LTE-FDD B13 @22.92dBm
LTE-FDD B14 @23.42dBm
LTE-FDD B66 @23.35dBm
LTE-FDD B71 @23.39dBm
WCDMA B2 @23.59dBm
WCDMA B4 @23.47dBm
WCDMA B5 @23.46dBm
Conditions
Power down
AT+CFUN=0 (USB disconnected)
WCDMA PF=64 (USB disconnected)
WCDMA PF=128 (USB disconnected)
WCDMA PF=256 (USB disconnected)
LTE Standard Module Series
EC25 Hardware Design
560.0
564.0
601.0
610.0
603.0
617.0
698.0
710.0
650.0
648.0
690.0
685.0
715.0
689.0
585.0
610.0
605.0
Typ.
8
0.83
1.55
1.24
1.07
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
Unit
uA
mA
mA
mA
mA
92 / 130
