Introduction
About This Document
This hardware installation guide contains procedures and safety requirements for installing the Brocade G720 Switch
into a rack system or as a stand-alone device. Also provided are steps to initially configure the switch for operation, verify
and monitor operation, replace switch field-replaceable units (FRUs), and install transceivers and cables. Complete
technical specifications for the switch are also included.
Supported Hardware and Software
The Brocade G720 Switch is introduced in the Fabric OS
fan assemblies and the rack mount kits supported on this device.
Table 1: Power Supply and Fan Assemblies
Part Number
XBR-G350WPSAC-F
XBR-G350WPSAC-R
NOTE
Fabric OS 9.x refers to any supported release within the 9.x generation of Fabric OS.
Table 2: Rack Mount Kits
Part Number
XBR-R000294
XBR-R000296
The Brocade G720 Switch requires optics that are labeled with an SEC designation.
The following image provides an example of an optic label with SEC in the description (32G LW-SEC 10km).
Broadcom
Description
350W AC power supply with nonport-side
exhaust airflow
350W AC power supply with nonport-side
intake airflow
Universal two-post mid-mount or flush-mount rack kit
Universal four-post fixed rack mount kit
®
9.0.0 release. The following tables list the power supply and
Introduced (OS)
Fabric OS 9.0.0
Fabric OS 9.0.0
Description
®
Brocade
G720 Switch Hardware Installation Guide
Currently Supported (OS)
Fabric OS 9.x
Fabric OS 9.x
G720-Install-IG101
7
