Introduction

This guide contains installation procedures and safety requirements for installing your switch into a rack system or as a
stand-alone device.
Also provided are steps to initially configure the Brocade
replace switch field-replaceable units (FRUs), and to install transceivers and cables. Complete technical specifications for
the switch are also included.

Supported Hardware and Software

The Brocade G730 Switch is introduced in the Fabric OS
supplies, the fan assemblies, and the rack mount kits supported on this device.
Table 1: Power Supply and Fan Assemblies
Part Number
XBR-1100WPSAC-F
XBR-1100WPSAC-R
XBR-ENT-FAN-80-F-2
XBR-ENT-FAN-80-R-2
Table 2: Rack Mount Kits
Part Number
XBR-R000294
XBR-R000296

Notes, Cautions, and Danger Notices

Notes, cautions, and danger statements may be used in this document.
NOTE
A Note provides a tip, guidance, or advice, emphasizes important information, or provides a reference to related
information.
CAUTION
A Caution statement alerts you to situations that can be potentially hazardous to you or cause damage to
hardware, firmware, software, or data.
DANGER
A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to
you. Safety labels are also attached directly to products to warn of these conditions or situations.
Contacting Technical Support for Your Brocade
If you purchased Brocade
provider for all your product support needs.
1100W (maximum), 100–240 VAC power supply FRU with nonport-side exhaust airflow
1100W (maximum), 100–240 VAC power supply FRU with nonport-side intake airflow
Fan assembly FRU with nonport-side exhaust airflow
Fan assembly FRU with nonport-side intake airflow
Universal two-post mid-mount or flush-mount rack kit
Universal four-post fixed flush-mount rack kit
®
