G720-Install-IG101 Installation Guide
Mounting the Device
Mounting Options
You can install the device in several ways:
•
As a stand-alone unit on a flat surface, for example, a table top. Use the rubber feet included with the shipment to
secure the device on the surface. No other equipment is required for desktop installation.
•
In a four-post EIA rack: You will need a Universal Four-Post Rack Kit (XBR-R000296) to install devices in EIA racks
that are between L-13.7 cm to 81.28 cm deep (L-5.0 in. to 32.0 in.), where L is the chassis depth.
•
In a two-post telco rack: You will need a Universal Two-Post Rack Kit (XBR-R000294) to install 1U and 2U devices in a
two-post telecommunications (telco) rack.
NOTE
Review the following precautions before mounting the device.
Precautions Specific to Mounting
The following precautions apply to mounting the device.
DANGER
Use safe lifting practices when moving the product.
DANGER
Mount the devices you install in a rack as low as possible. Place the heaviest device at the bottom and
progressively place lighter devices above.
CAUTION
Make sure the airflow around the front and back of the device is not restricted.
CAUTION
Never leave tools inside the chassis.
CAUTION
Do not use the port cover tabs to lift the module. They are not designed to support the weight of the module,
which can fall and be damaged.
CAUTION
To prevent damage to the chassis and components, never attempt to lift the chassis using the fan or power
supply handles. These handles were not designed to support the weight of the chassis.
Broadcom
®
Brocade
G720 Switch Hardware Installation Guide
G720-Install-IG101
19
