Broadcom Brocade G720 Hardware Installation Manual page 72

G720-Install-IG101 Installation Guide
Power Supply Specifications (Per PSU)
Maximum
Power Output
Supply Model Power
Rating (DC)
XBR- 350W
G350WPSAC-F
(nonport-side
exhaust airflow)
XBR- 350W
G350WPSAC-R
(nonport-side
intake airflow)
Fibre Channel Data Transmission Ranges
Port Speed (Gb/s)
8
10
16
32
64
Broadcom
Input Voltage
100–240 VAC 50/60 Hz (nominal)
(nominal)
47–63 Hz (range)
90–264 VAC
(range)
100–240 VAC 50/60 Hz (nominal)
(nominal)
47–63 Hz (range)
90–264 VAC
(range)
Cable Size (Microns)
50
62.5
9
50
62.5
9
50
62.5
9
50
62.5
9
50
62.5
9
Maximum
Input Line
Input
Frequency
Current
4.5A
4.5A
Short Wavelength (SWL)
35m (115 ft) (OM2)
100m (328 ft) (OM3)
125m (410 ft) (OM4)
15m (49 ft)
N/A
35m (115 ft) (OM2)
100m (328 ft) (OM3)
125m (410 ft) (OM4)
15m (49 ft)
N/A
35m (115 ft) (OM2)
100m (328 ft) (OM3)
125m (410 ft) (OM4)
15m (49 ft)
N/A
70m (230 ft) (OM3)
100m (328 ft) (OM4)
N/A
N/A
70m (230 ft) (OM3)
100M (328 ft) (OM4 and OM5)
N/A
N/A
®
Brocade G720 Switch Hardware Installation Guide
Input Line
Maximum Inrush Current
Protection
Line fused 50A peak @ 240 VAC for <10
ms, 10–150 ms, <15A peak.
50A peak @ 240 VAC at cold
start for <10 ms.
15A peak for cycles 10–150 ms.
<3.5A peak for >150 ms.
Line fused 50A peak @ 240 VAC for <10
ms, 10–150 ms, <15A peak.
50A peak @ 240 VAC at cold
start for <10 ms.
15A peak for cycles 10–150 ms.
<3.5A peak for >150 ms.
Long Wavelength (LWL)
N/A
N/A
10 km (6.2 miles)
N/A
N/A
10 km (6.2 miles)
N/A
N/A
10 km (6.2 miles)
N/A
N/A
10 km (6.2 miles)
N/A
N/A
N/A
G720-Install-IG101
72
